1U rackmount, 7x Gigabit Ethernet, 1x Combo port (SFP or Gigabit Ethernet), 1xSFP+ cage, 9 cores x 1.2GHz CPU, 2GB RAM, LCD panel, Dual Power supplies, SmartCard slot, RouterOS L6
The new updated revision of CCR1009 is here.
We attempted to combine all the customer feedback and best practice in CCR device manufacturing that we learned over the last three years, since the first CCR1009 devices were launched.
Important changes
No switch-chip - the device now features only fully independent Ethernet ports each with a direct connection to the CPU, allowing to overcome previous shared 1Gbit limitation from switch-chip ports and utilize full potential of CPU processing power on those ports.
Combo-port - a single 1Gbit software interface that has two hardware interfaces - an SFP cage and a Gigabit Ethernet port, allowing you to use any type of connection available to you.
It is also possible to switch between both physical interfaces in RouterOS.
In an event of disconnect the combo-port provides hardware fail-over feature.
100Mbps SFP support - this is our first device that supports 100BASE-LX/100BASE-SX/100BASE-BX fiber modules, as well as standard 1.25G SFP modules.
More throughput - because the ports are now directly connected to the CPU, the new CCR1009 can achieve even higher throughput.
Specifications
Details
Product code: CCR1009-7G-1C-1S+
Architecture: TILE
CPU: TLR4-00980
CPU core count: 9
CPU nominal frequency: 1.2 GHz
Dimensions: 443 x 175 x 44 mm
RouterOS license: 6
Operating System: RouterOS
Size of RAM: 2 GB
Storage size: 128 MB
Storage type: NAND
MTBF: Approximately 200'000 hours at 25C
Tested ambient temperature: -20°C to 60°C
IPsec hardware acceleration: Yes
Powering
Details
Number of AC inputs: 2
AC input range: 100-240
Number of DC inputs: 1 (PoE-IN)
Max power consumption: 39 W
Max power consumption without attachments: 34 W
Cooling type: 2 fans
PoE in: Passive PoE
PoE in input Voltage: 15-57 V
Ethernet
Details
10/100/1000 Ethernet ports: 7
Ethernet Combo ports: 1
Fiber
Details
SFP+ ports: 1
Peripherals
Details
Number of SIM slots: 1 Smart card (Mini SIM)
Memory card type: microSD
Memory Cards: 1
Serial console port: RS232
Number of USB ports: 1
USB Power Reset: Yes
USB slot type: microUSB type AB
Max USB current (A): 1
Other
Details
CPU temperature monitor: Yes
Current Monitor: Yes
PCB temperature monitor: Yes
Voltage Monitor: Yes
Beeper: Yes
Certification & Approvals
Details
Certification: CE, EAC, ROHS
IP: IP20
