Powerful 10xGigabit port router with a Quad-core 1.4Ghz CPU, 1GB RAM, SFP+ 10Gbps cage and desktop case with rack ears.
RB4011 series - amazingly powerful routers with ten Gigabit ports, SFP+ 10Gbps interface and IPsec hardware acceleration for a great price!
The RB4011 uses a quad core Cortex A15 CPU, same as in our carrier grade RB1100AHx4 unit. The unit is equipped with 1GB of RAM, can provide PoE output on port #10 and comes with a compact and professional looking solid metal enclosure in matte black.
RB4011iGS+RM (Ethernet model) includes two rackmount ears that will securely fasten the unit in a standard 1U rack space.
Note: Passive DAC (MikroTik S+DA0001/S+DA0003) are not supported.
Specifications
Details
Product code: RB4011iGS+RM
Architecture: ARM 32bit
CPU: AL21400
CPU core count: 4
CPU nominal frequency: auto (533 - 1900) MHz
Switch chip model: RTL8367SB
Dimensions: 228 x 120 x 30 mm
RouterOS license: 5
Operating System: RouterOS (v7 only)
Size of RAM: 1 GB
Storage size: 512 MB
Storage type: NAND
MTBF: Approximately 200'000 hours at 25C
Tested ambient temperature: -40°C to 70°C
IPsec hardware acceleration: Yes
Powering
Details
Number of DC inputs: 2 (DC jack, PoE-IN)
DC jack input Voltage: 12-57 V
Max power consumption: 33 W
Max power consumption without attachments: 18 W
Cooling type: Passive
PoE in: Passive PoE
PoE in input Voltage: 18-57 V
PoE-out
Details
PoE-out ports: Ether10
PoE out: Passive PoE up to 57V
Max out per port output (input 18-30 V): 600 mA
Max out per port output (input 30-57 V): 420 mA
Max total out (A): 600 mA
Ethernet
Details
10/100/1000 Ethernet ports: 10
Fiber
Details
SFP+ ports: 1
Peripherals
Details
Serial console port: RJ45
Other
Details
PCB temperature monitor: Yes
Voltage Monitor: Yes
Certification & Approvals
Details
Certification: CE, EAC, ROHS
IP: IP20
