Dual-band 2.4 / 5GHz wireless access point for mounting on a ceiling or wall with two Gigabit Ethernet ports (one with PoE output), 802.11ac support and IPsec hardware encryption support.
The cAP ac is a very capable and powerful wireless access point that looks beautiful on both walls and ceilings.
The concurrent dual band wireless radio supports dual chain 2 GHz 802.11b/g/n and 5 GHz in a/n/ас standards, and will provide coverage in 360 degrees around it.
Even though the radio supports repeater mode, the two Ethernet ports give you the ability to extend your network with cables, even if PoE power is required, since the cAP ac supports 802.3af/at PoE input on the first port, and passive PoE output on the second port.
Device supports IPsec hardware acceleration too.
- cAP ac supports 2412-2484MHz and 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).
Specifications
Details
Product code: RBcAPGi-5acD2nD
Architecture: ARM 32bit
CPU: IPQ-4018
CPU core count: 4
CPU nominal frequency: 716 MHz
Switch chip model: IPQ-4018
Dimensions Round case: ⌀ 136 mm, height: 30 mm; Square case: 145 mm x 145 mm x 30 mm
RouterOS: license 4
Operating System: RouterOS
Size of RAM: 128 MB
Storage size: 16 MB
Storage type: FLASH
MTBF: Approximately 100'000 hours at 25C
Tested ambient temperature: -40°C to 50°C
IPsec hardware acceleration: Yes
Wireless capabilities
Details
Wireless 2.4 GHz Max data rate: 300 Mbit/s
Wireless 2.4 GHz number of chains: 2
Wireless 2.4 GHz standards: 802.11b/g/n
Antenna gain dBi for 2.4 GHz: 2
Wireless 2.4 GHz chip model: IPQ-4018
Wireless 2.4 GHz generation: Wi-Fi 4
Wireless 5 GHz Max data rate: 867 Mbit/s
Wireless 5 GHz number of chains: 2
Wireless 5 GHz standards: 802.11a/n/ac
Antenna gain dBi for 5 GHz: 2.5
Wireless 5 GHz chip model: IPQ-4018
Wireless 5 GHz generation: Wi-Fi 5
WiFi speed: AC1200
Ethernet
Details
10/100/1000 Ethernet ports: 2
Powering
Details
Number of DC inputs: 1 (PoE-IN)
Max power consumption: 24 W
Max power consumption without attachments: 13 W
Cooling type: Passive
PoE in: 802.3af/at
PoE in input Voltage: 17-57 V
PoE-out
Details
PoE-out ports: Ether2
PoE out: Passive PoE up to 57V
Max out per port output (input 18-30 V): 500 mA
Max out per port output (input 30-57 V): 400 mA
Max total out (A): 500 mA
Certification & Approvals
Details
Certification: CE, FCC, IC, EAC, ROHS
Other
Details
Mode button: Yes
